Hypro 4101N 4-Roller Pump with 1/2″ Hollow Shaft
Ni-Resist 4-Roller Pump w/ Super Rollers, Viton Seals, 7.2 GPM, 150PSI, 2600RPM, 3/4″ NPT, 1/2″ Hollow Shaft
Performance Information
- Max. flow: 7 gpm/26.5 lpm at 2600 rpm
- Max. pressure: continuous 100 psi/6.9 bar
- Max. pressure: intermittent 150 psi/10.3 bar
- Max. rated speed: 2600 rpm
Other Attributes
- Rollers: Super Rollers standard (Poly, Teflon and Buna-N available)
- Housing: Ni-Resist
- Port size: 3/4″ NPT
- Shaft size: 5/8″ solid
- Pump shaft rotation: CW
- Shaft Seals: Viton standard (Buna-N available)
- Available shaft adapters
- Rotor: Cast Iron, Ni-Resist or Silvercast
- Standard rotation directly couples to gasoline engines
- Special torque arm and spraysmarter kit is available for gas engines
Hypro Part Number
4101N-H – Hypro 4101N 4-Roller Pump with 1/2″ Hollow Shaft
